26W 360 rotatable COB LED downlight

26W 360 rotatable COB LED downlight

Place of Origin : china
Brand Name : EWIN
Certification : CE ROHS
Model Number : EW-OCL-COB-26W-WW
MOQ : 1 Piece/Pieces
Price : US $ 46.8 - 55.6 / Piece
Packaging Details : 12pcs in one carton(52x34x34CM)
Delivery Time : usually 7-10 working days
Payment Terms : T/T, Western Union
Supply Ability : 50,000 Piece/Pieces per Month
Input Voltage(V) : AC100-240V 50/60Hz
Lamp Luminous Flux(lm) : 2400-2600
Lamp Luminous Efficiency(lm/w) : 100
CRI (Ra>) : 82
Working Lifetime(Hour) : 50000
Install Style : Downlights
Light Source : LED
Item Type : Downlights
LED Light Source : LED
Warranty(Years) : 3
Lamp Power(W) : 30
Color Temperature(CCT) : white, warm white, cold white,red,green,blue,yellow
Working Temperature(℃) : -40 - 45
watts : 3W-50W are available
Lamp Body Material : Aluminum
IP Rating : IP33
Beam Angle : 30°/60°
Color Temperature : 2000k-7000k
Working Voltage : 50-70VDC
Contact Now

26W 360 rotatable COB LED downlight


1.Output: 2400-2600lm
2.CRI: >82
3.Rotatable: 360 degree
4.Dimmable:Triac or Dali
5.Certificates: CE/RoHS/SAA/SASO

26W 360 rotatable COB LED downlight

Products Features:
(1)LED Power: 26W.
(2)Lamp Consumption:30W.
(3)Output: 2400-2600lm.

(4)Input voltage:100-270v AC, 50-60hz
(5)Beam Angle:30°/60°
(6)CRI:> 80.
(7)Working Temperature:-40°C-45°C.
(8)Storage Temperature: -25°C-65°C.
(9)Color of housing: white, black, silver.
(10)Life span: 50,000+hrs.
(11)Certificate: CE/RoHS/SASO
(12)Warranty: 3 years.

COB Parameter:
(1)PCB: Ceramic.
(2)Chip Brand: Epistar 10*23.
(3)Output: 2400-2600lm.
(4)Chip Qty: 420 pcs.
(5)CRI> 82.
(7)Current: 500-600mA.

Driver Parameter:
(1)Brand: Lifud (LED Friend).
(2)Input:100-277v AC.
(3)Output: 27-42vDC, 500mA.
(4)Power effect: 0.9-0.97.
(5)Power Efficiency: 85%

Dimmable: Triac or Dali is available.
Meanwell PLD-16-350 is optional.

Product Datasheet:

Part No.ColorCCTOutput
EW-OCL-COB-26W-WWwarm white2400-2500k1250-1300lm
EW-OCL-COB-26W-NWnatural white4000-4500k1300-1400lm
EW-OCL-COB-26W-CWcool white5900-6300k1350-1500lm


IES Test:(please contact us to get the IES file)
